Multi-channel Polarization Extinction Ratio Mater,PER-8606

PERM-8606 Multi-channel Polarization extinction ratio meter is a professional equipment for polarization extinction ratio (PER) testing of polarization preserving devices, polarization degree of polarization (DOP) testing of light sources, on-line monitoring of polarization preserving optical fibers and fiber optic patch cords, and testing of other polarization preserving devices. It supports dual-channel or multi-channel simultaneous data measurement, and features large dynamic range, optional configuration of multiple frequency bands, high precision and high stability.

Multi-channel Polarization Extinction Ratio Mater,PER-8606

Product Description

PERM-8606 Multi-channel Polarization extinction ratio meter is a professional equipment for polarization extinction ratio (PER) testing of polarization preserving devices, polarization degree of polarization (DOP) testing of light sources, on-line monitoring of polarization preserving optical fibers and fiber optic patch cords, and testing of other polarization preserving devices. It supports dual-channel or multi-channel simultaneous data measurement, and features large dynamic range, optional configuration of multiple frequency bands, high precision and high stability.

Model:PER-8606

Place of Origin: Shenzhen, China

 Key Features:

  • Can detect polarization extinction ratio (PER) and insertion return loss over a large dynamic range, with a maximum PER of up to 50dB;
  • Maximum input power +5dBm, fast detection speed, high precision and stability;
  • Plug-gable module, the number of channels can be customized;
  • Bias-preserving fiber optic axis angle test, support online monitoring;
  • Supports free space input, insertion loss, optical power, extinction ratio, optical axis angle, polarization degree on the same screen;
  • Supports RS232 interface;
  • Multi-band optional.

Application:

  • Spectral ratio measurements;
  • Y waveguide measurements and additional loss;
  • Extinction ratio measurement of bias-preserving optical fibers;
  • Bias-preserving optical device extinction ratio measurements;
  • Bias-conserving connector extinction ratio measurements;
  • Polarization measurement of light sources and polarization axis angle measurement.

Technical Parameters:

Model PER-8606
Wavelength Range 600-1100nm 1200-1630nm
Input Power Range +10dBm~-70dBm
PER dynamic range 40dB 50dB
Input Optical Power Range 40dB 50dB
+10~-20dBm 40dB +10~-20dBm 50dB
+10~-30dBm 30dB +10~-30dBm 40dB
PER accuracy +10~-40dBm 20dB +10~-40dBm 30dB
PER≤2dB:≤±0.05dB
PER<30dB:<±0.3dB

Note: Other band lengths are available for customization; higher input power is available for customization.
