LC UPC Multi Mode Connector LC-UPC-MM

All components of/and the final product are designed and tested to conform the requirements of IEC 60874-7, CECC 86115-801, Bellcore/Telcordia GR-326, EIA/TIA 604-3A, EIA/TIA 568, ISO/IEC 11801 2nd Ed., EN 50173, JIS C5973 F04, ICEA-596, IEC60793-2-10 A1a, ITU-T G.651 or IEC60793-2-10 A1b or ITU-T G.652 (depending on fiber), Belcore/Telcordia GR-409-CORE, IEC 793, IEC 794-1-E1, IEC 794-1-E3, UL1666/901 (UL-cable) and EIA/TIA455.

LC UPC Multi Mode Connector LC-UPC-MM

Model: LC-UPC-MM

Place of origin: Shenzhen

Key Features:

1, Low insertion loss and back reflection loss;

2, Ferrule end surface predomed;

3, Precision anti-rotation key and corrosion resistant body;

4, UL-rated plastic housing;

5, Boots in a variety of colors;

6, Telcordia style boots;

7, Free-floating ceramic ferrule.

Parameters of LC series:

Paramter

Singlemode(PC)

Singlemode(APC)

Multimode   (PC)

Insertion   loss

≤0.2   dB

≤0.2dB

≤0.2dB

Return   Loss

≥50   dB

≥65   dB

≥35   dB

Operating   Temperature

-40°C   to +80°C

-40°C   to +80°C

-40°C   to +80°C



Availability:

The connector can be supplied as a pre-assembled one-piece connector or as connector kits.

Clips are available for duplex connectors.

Housing kits without ferrule are available.

 Applications:

1, CATV

2, Active device termination

3, Telecommunicationnetworks

4, Metro

5, Local Area Networks (LANs)

6, Data processing networks

7, Test equipment

8, Premise installations

9, Wide Area Networks (WANs)

Follows are for your choice:







Shenzhen Neofibo Technology Limited was founded in 2008, locates Shenzhen China. Neofibo has dedicated to become the professional supplier for fiber optic polishing solutions and aims to make our customers’ fiber connectivity more reliable.

During last 14 years, we have been comprised of a group of experienced fiber optic professionals in areas of connector polishing and assembling, outside plant installation, transmission system, datacom, CATV and testing. Neofibo could provide products and service for you, whether you are fiber optic scientist working in multi-gigabit, DWDM, EDFA applications, maintenance engineer  for optical connecting system, an outside plant contractor providing splicing and testing, a datacom manager who works in multimode-to-single mode conversion or you are an optical fiber component manufacturer who needs lots of high quality pigtails, consumables and tools, you can count on us to offer you the verified solution.

Neofibo is focusing on the field of fiber optic polishing solutions.

We specialize in manufacturing fiber optic polishing machine, design various optical fiber connectors polishing fixtures, provide completed polishing process and materials for all kinds of fiber optic connectors.

Neofibo could provide the whole sets of production equipments for fiber optic patch cord, such as fiber optic polishing, end face inspection microscope, functional inspection and detection, raw materials as fiber optic cables and fiber connectors, processing tools and cleaning consumables.

Neofibo can provide not only products, but also technical services and R & D support.

Neofibo should be your partner forever.





















What does NEOFIBO offer?

We offer full range of quality and comprehensive fiber optic products, including Patchcord Production Machine, polishing jigs, as Seikoh Giken, Senko, Domaille or customized ones; Polishing Consumables, Tools, Cleanings, Tool Kits, Testing Equipment, Splice Items. We commit to offer you Attractive Price, Excellent Quality and Fast Delivery!

What will be the delivery cost?

All price listed are FOB Shenzhen. Your nominated courier is acceptable. Otherwise, we will use FEDEX, DHL, UPS or any other forwarder per confirmation and charge accordingly.

How the goods will be delivered?

For normal stock items, they will be dispatched within 1-2 business days after payment confirmation. However, for items out of stock, estimated leadtime will be 3-10 working days.

How can I order the goods?

Neofibo is pleased to offer our valuable customers three ordering channels.  e.g.:  Online Ordering, Fax Order Form and Issuing Formal Purchasing Order by mail.

How is the warranty for NEOFIBO product?

All products are warranted by NEOFIBO (consumables, normal tear and wear excluded) for one year after date of purchase. Any part defected in material or workmanship and returned to NEOFIBO, as NEOFIBO designates, shipping costs prepaid, will be, as the exclusive remedy, repaired or replaced, at NEOFIBO’s option.
